cod. | mm. | pz/ pcs | A | B | C | ØD | E | F | G | H | S | bullone | viti | asole | binario | Barcode | CodTek |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
395IX.P | PICCOLO | 1 | 180 | 150 | 135 | Ø59 | 125 | 100 | 100 | 100 | 15 | M8 | - | n.4 18x25 | art.399IX.P | 8033039312891 | ARU039501IX |
395IX.M | MEDIO | 1 | 300 | 150 | 220 | Ø86 | 250 | 100 | 140 | 135 | 20 | M12 | M16x35 | n.6 18x25 | art.399IX.M | 8033039313775 | ARU039502IX |
395IX.G | GRANDE | 1 | 500 | 200 | 380 | Ø126 | 440 | 150 | 202 | 197 | 30 | M12 | M16x35 | n.6 22x30 | art.399IX.G | - | - |
